PP Corrugated Bottle Tray — Base Pallet Tray for Secure Bottle Positioning
PPBOXY is proud to introduce the Hollow Board Bottle Tray, a game-changer for businesses that store or transport bottled products. This tray is expertly crafted from high-quality polypropylene, offering a sturdy, reliable solution for manufacturers, warehouses, and distributors who handle bottled goods.
Features & Benefits of the Hollow Board Bottle Tray
The PPBOXY corrugated bottle tray is a die-cut base tray with recessed cells that hold individual bottles upright and securely positioned on a pallet. Unlike flat layer pads that simply separate stacked layers, a bottle tray provides three-dimensional cradling at the base — each bottle sits in its own contoured pocket, preventing lateral movement, tipping, and contact damage during storage and transport.
Precision Die-Cut Cell Design
Every bottle tray is custom die-cut to match your specific bottle diameter, base shape, and pallet layout. Round cells for wine and spirit bottles, rectangular pockets for juice containers, or irregular profiles for specialty products — PPBOXY produces trays with cell dimensions that provide a snug, rattle-free fit. Cell depth can be adjusted from shallow定位 grooves to deep cradles depending on your bottle stability requirements.
Waterproof and Chemical-Resistant
Manufactured from polypropylene corrugated board, these trays will not absorb moisture, warp in humid conditions, or degrade when exposed to chemical spills. This is critical for beverage production environments where washdown routines, condensation, and product spills are daily occurrences. Unlike cardboard bottle trays that weaken and collapse when wet, PP trays maintain full structural integrity cycle after cycle.
Stackable for Space Efficiency
The rigid corrugated structure provides excellent vertical load-bearing, allowing filled trays to be stacked multiple layers high without compression damage. Stackability maximizes warehouse cube utilization and reduces freight costs per unit shipped. Anti-slip surface options are available for applications requiring extra stacking stability.
Reusable and Cost-Effective
PP corrugated bottle trays withstand 50–200 handling cycles, dramatically reducing per-trip packaging costs compared to single-use cardboard or molded pulp alternatives. At end of life, the material is 100% recyclable (PP #5), supporting your sustainability targets and corporate environmental commitments.
For vertical cell separation between bottles within a case, see our PP corrugated dividers. For flat layer-to-layer protection between pallet tiers, pair these trays with our layer pads dividers or protective plastic layer pads.
Applications of PP Corrugated Bottle Tray
PPBOXY corrugated bottle trays are used across industries where bottled products require secure base positioning and stable pallet stacking:
Beverage and Brewery
The most common application — glass beer bottles, wine bottles, spirit bottles, and juice containers all benefit from recessed cell positioning that prevents lateral shift during pallet transport. Compatible with both manual and semi-automated palletizing lines.
Food and Condiment Manufacturing
Sauce bottles, oil bottles, vinegar containers, and other food-grade liquids require stable base cradling during distribution. PP trays are food-contact compliant and withstand washdown environments in food processing facilities.
Pharmaceutical and Healthcare
Medicine bottles, syrup containers, and supplement jars need precise base positioning to maintain upright orientation during cold-chain and ambient distribution. PP material meets FDA and EU food-contact standards and is resistant to temperature cycling from -20°C to +80°C.
Chemical and Industrial Fluids
Cleaning agents, lubricants, anti-rust oils, and specialty chemicals require trays that resist chemical spills and prevent cross-contamination. The waterproof, non-absorbent PP material contains incidental spills within cell pockets rather than wicking liquid across the tray surface like cardboard would.
Bottle Tray vs Layer Pad vs Divider — Which Do You Need?
All three products serve bottle protection, but they work at different levels inside a pallet load:
| Criteria |
Bottle Tray |
Layer Pad |
Corrugated Divider |
| Function |
Base cradling — holds bottles upright from below |
Layer separation — sits between stacked tiers |
Vertical separation — divides bottles side-by-side |
| Orientation |
Horizontal, at the bottom of each layer |
Horizontal, between layers |
Vertical, within a single layer |
| Structure |
Recessed cells/pockets cut into board |
Flat sheet (solid or corrugated) |
Vertical cell walls between bottles |
| What it prevents |
Tipping, lateral shift, base sliding |
Layer-to-layer abrasion, compression damage |
Side contact, vibration clinking |
| Typical position |
Bottom of each bottle row |
Between bottle rows on pallet |
Inside a case between bottles |
| Reusable |
50–200 cycles |
50–200 cycles |
50–200 cycles |
| Best combined with |
Layer pad on top + dividers inside case |
Bottle tray below + divider inside case |
Bottle tray below + layer pad on top |
In practice, most professional palletizing setups use two or three together:
- Bottle tray at the base of each layer → prevents tipping
- Corrugated divider between bottles within the layer → prevents side contact
- Layer pad on top of the layer → protects the next layer above
This three-product system provides complete protection in all three dimensions: base stability, lateral separation, and vertical load distribution.
For corrugated dividers, visit our PP corrugated dividers page. For layer protection, see our layer pads dividers or corrugated plastic layer pads.
What is a PP corrugated bottle tray?
A PP corrugated bottle tray is a die-cut base tray made from polypropylene corrugated board with recessed cells or pockets that hold individual bottles upright and securely positioned on a pallet. Unlike flat layer pads, a bottle tray provides three-dimensional cradling at the base — each bottle sits in its own contoured pocket, preventing tipping, lateral movement, and contact damage during storage and transport.
What is the difference between a bottle tray, a layer pad, and a corrugated divider?
A bottle tray sits at the base of each bottle row and provides recessed cells that hold bottles upright from below. A layer pad is a flat sheet placed between stacked layers of bottles on a pallet for horizontal layer-to-layer protection. A corrugated divider has vertical cell walls that separate bottles side-by-side within a single layer. Most professional palletizing setups use two or all three together for complete three-dimensional protection: bottle tray (base stability), divider (lateral separation), and layer pad (vertical load distribution).
Can bottle trays be custom die-cut for different bottle sizes?
Yes. All PPBOXY bottle trays are custom die-cut to match your specific bottle diameter, base shape, and pallet layout. Round cells for wine and spirit bottles, rectangular pockets for juice containers, and irregular profiles for specialty products are all available. Simply provide your bottle dimensions and pallet configuration — we will produce trays with cell dimensions that provide a snug, rattle-free fit.
Are PP bottle trays waterproof?
Yes. Polypropylene corrugated board is inherently waterproof with moisture absorption below 0.01%. PP bottle trays will not absorb liquid, warp, or lose structural integrity in humid environments or when exposed to washdown routines, condensation, or product spills. This makes them far superior to cardboard bottle trays, which weaken and collapse when wet.
How many times can PP bottle trays be reused?
PP corrugated bottle trays typically withstand 50–200 handling cycles depending on bottle weight, stack height, and handling conditions. With proper care — avoiding sharp impacts, excessive compression, and temperatures above 80°C — most industrial users achieve 100+ reuse cycles. This translates to a 60–80% cost reduction compared to single-use cardboard or molded pulp trays over the product lifecycle.
What sizes are available for bottle trays?
PPBOXY offers standard tray sizes matching common pallet formats: 1000×1000mm, 1100×1100mm, and 1200×1000mm. Custom sizes are available to match specific container configurations, case dimensions, or non-standard pallet formats. Cell depth, wall height, and pocket layout are all customizable. Contact PPBOXY with your bottle specifications and pallet dimensions for a free tray design and quote.
Hollow Board Bottle Tray
